Chain Fusion Technology

ICP enables direct interoperability with all major blockchains, including Bitcoin, Ethereum, other EVMs (and soon Solana), without relying on any trusted intermediary. Unique compared to other blockchains, ICP smart contracts can read from and write to different chains, enabling developers to write smart contracts spanning different chains. This is chain fusion.

The common web3 pattern is building dapps from different blockchains, for instance Ethereum or Solana to store assets, IPFS or Arweave for serving frontends, and Arbitrum or Optimism for the bulk of smart contract computation. However, building dapps like this is very cumbersome. Developers must adapt to various programming models, transaction costs, and settlement times. Chain fusion tremendously simplifies multi-chain dapp development, making it as straightforward and native as building on a single environment.

Example Code

To showcase how powerful chain fusion is, here is a simple example that shows three chains interacting in one smart contract: a single ICP smart contract that can custody Bitcoin and programmatically trigger sending it based on events observed on a Ethereum DeFi smart contract.

This code snippet is written in the Motoko programming language but is also possible for Rust, TypeScript, Python, and other languages.

Deploy the contract in online editor

  import evm "ic:a6d44-nyaaa-aaaap-abp7q-cai";
  import ic "ic:aaaaa-aa";
  import Cycles "mo:base/ExperimentalCycles";
  import Timer "mo:base/Timer";

  //Actor is the computational unit of ICP smart contract
  actor {
    let EVM_FEE = 1000;
    let BITCOIN_FEE = 1000;

     //Function checks the logs of an ETH smart contract for an event
     //If a particular event is found, it sends bitcoin to an address
     func check_evm_log() : async () {
      Cycles.add<system>(EVM_FEE);
      let log = await evm.eth_getLogs(
        #EthMainnet(null),
        null,
        {
          // dummy address. Replace with the right one
          addresses = ["address"];
          fromBlock = ? #Finalized;
          toBlock = ? #Finalized;
          //dummy topics to look at. Replace with topics of interest
          topics = ?[["topic1", "topic2"]];
        },
      );
      switch log {
        case (#Consistent(#Ok(_))) {
          // if we get a consistent log, send bitcoin
          await send_bitcoin();
        };
        case _ {};
      };
    };

    // Function that sends bitcoin. This is used by check_evm_log()
    func send_bitcoin() : async () {
      Cycles.add<system>(BITCOIN_FEE);
      await ic.bitcoin_send_transaction({
        transaction = "eef";
        network = #testnet;
      });
    };

    // Check for evm logs every 2 seconds
    let _ = Timer.setTimer<system>(#seconds 2, check_evm_log);
  };



Expand

How it is solved today

Developers today rely on trusted intermediaries acting as a bridge that make wrapped copies of native tokens for usage on other blockchains. These bridges are slow, inconvenient, but most importantly: they are the achilles heel of web3, this is where majority of hacks happen, tens of billions of dollars of assets have been lost.

There are also rollups, which rely on the security of the base L1 chain. However, it is still not possible to easily move assets arbitrarily between different rollup chains as each step transfer relies on the main chain thereby, resulting in expensive L1 gas fees and settlement delays lasting days. Rollups also do not solve smart contract interoperability across chains, such as between Bitcoin, Ethereum and Solana, etc.

The two pillars of chain fusion

True multi-chain capability requires enabling smart contracts to read and write across chains. For instance, you can write a single ICP smart contract that can custody Bitcoin and programmatically trigger sending it based on events observed on a Ethereum DeFi smart contract.

Chain-key cryptography is the scientific breakthrough that allows ICP smart contracts to create and sign transactions that are executed on other blockchains – writing to other blockchains directly.

Direct network integration enables ICP smart contracts to query data and smart contracts from other blockchains, validated by ICP consensus – reading from other blockchains.

Use cases of chain fusion

Explore Chain Fusion technology use cases, including executing ICP smart contracts on other chains and asset storage like Bitcoin and Ethereum.

These applications range from automating tasks on Ethereum to creating ICP smart contracts that manage Bitcoin/Ethereum. Developers can also use ckBTC and ckETH to efficiently build DeFi services, bypassing high costs and delays.

Web-based multi-chain wallet

A key problem with hosting traditional wallets such as MetaMask on a smartphone or laptop is the risk of theft by extortion, especially in the developing world. For example, a robber might put a victim up to a wall, and force them to open their phone under threat of violence. If the victim maintains crypto in a traditional wallet, it will be seen and they will lose their crypto.

Chain key makes it possible to create purely web-based wallets, backed by a canister smart contract that maintains the crypto. Authentication to such wallets can involve Internet Identity, Google SSO, or usernames and passwords as required. These can be opened using a web browser tab in Incognito mode, which leaves no trace of the wallet when closed.

The OISY wallet is a great example. It can custody any ICP asset (including chain key twins), native bitcoin, native bitcoin BRC20 tokens, and native Ethereum assets, as required. Self-custodied Ethereum assets can be used in Ethereum DeFi using the WalletConnect functionality it supports. Users gain convenience and a better experience, and superior security.

Cron jobs on Ethereum from ICP

A key challenge involved when hosting DeFi and other services using Ethereum smart contracts is the secure initiation of regular jobs. Oftentimes, smart contract jobs are initiated using external scripts running on insecure clouds such as Amazon Web Services, where the private key they maintain to make the calls is vulnerable in the same way the private keys used by hot wallets are.

The Internet Computer provides a solution. Canister smart contracts have an API that allows them to schedule their secure automatic execution for as long as needed into the future. Using EVM RPC, canisters can be used to initiate time-based calls into Ethereum smart contracts too – without a private key being made vulnerable.

in progress

Calling smart contracts on Ethereum from ICP using EVM RPC

The Internet Computer makes it possible to build almost any online service fully on-chain, in a full stack decentralization model, which can be augmented by placing the service under the control of an SNS DAO to automate its maintenance. This is because canister smart contracts can hold up to 400GiB of memory each, and run in parallel with great efficiency. Moreover, they can directly serve interactive web-based user experiences to users by processing HTTP requests, thanks to ICP’s reverse-gas model (canister smart contracts pay for their own execution using “cycles” that they have been charged with). Now they can also be trustlessly combined with DeFi and other functionality Ethereum hosts in a World Computer paradigm.

Ethereum Virtual Machine Remote Procedural Calls (EVM RPC) make it possible for Internet Computer canister smart contracts to interact with smart contracts on any blockchain which supports the Ethereum JSON-RPC protocol. Advanced fully decentralized Web3 services can be created that maintain the UX and heavy data storage and processing on the Internet Computer, while relying on Ethereum DeFi where financial rails are needed.

EVM RPC in beta testing

Unlimited multi-chain via edge routing

Thus far, the Internet Computer network has only directly integrated with the Bitcoin and Ethereum networks, enabling it to produce twins of assets hosted by those networks. However, more broad multi-chain functionality is easily produced.

The Internet Computer enables hosted smart contracts to create accounts on any other blockchain, and sign transactions that can run on their networks. Transaction routing can be performed by the UX of Web3 services.

The UX of a Web3 service can provide very fast, and totally decentralized, edge routing for transactions. For example, when a canister smart contract has created a transaction for execution on another blockchain, the UX (e.g JavaScript running in the web browser) can retrieve the signed transaction by making a call to the smart contract, and then push it to the online API of a node in the destination network, then poll for the result.

Bitcoin twin: ckBTC

Developers use ICP to bring smart contract functionality to Bitcoin. This new solution brings a new challenge: Bitcoin costs and wait times. No matter how fast a ICP smart contract is, moving Bitcoin will have the costs and wait times of the Bitcoin network.

To address this, developers also use ckBTC (“chain key bitcoin”). This is a trustless "Bitcoin twin" hosted on ICP that can be used by ICP smart contracts to move Bitcoin cheaply and quickly. This is possible because ICP nodes talk to Bitcoin nodes to download the Bitcoin network’s blocks and maintain its Unspent Transaction Output (UTXO) set. CkBTC can be directly processed by canister smart contract logic and transferred with 1 second finality at near zero cost.

Canister smart contracts can be used to provide web-based wallets, and other Web3 services, that directly incorporate bitcoin – for example, OpenChat allows chain key bitcoin to be transferred via instant chat messages. Canisters can also be used to build a new generation of “Bitcoin DeFi” services.

To create ckBTC, a user transfers their bitcoin to a ckBTC address provided by their wallet (e.g. see functionality provided at the NNS). Their ckBTC twin can then be sent to any other ckBTC address, almost instantly for a tiny fee, or directly to a standard Bitcoin address, causing the bitcoin twin to return to its native form.

Ordinals and BRC20

Creating Bitcoin Ordinals can be expensive and slow. ICP can help here too. ICP canister smart contracts can use the Bitcoin API to process bitcoin, and also Ordinals, which are used to create and transfer NFTs on the Bitcoin blockchain. Fully decentralized Web3 services on the Internet Computer have taken advantage of the functionality to create marketplaces for Ordinals e.g. Bioniq.

The processing of bitcoin and Ordinals involves the ICP protocol processing ECDSA cryptography behind the scenes. However, inscribing Ordinals and creating and processing BRC20 assets (e.g. meme coins that piggyback on Bitcoin) involves Schnorr cryptography, which ICP now also supports.

Because ICP supports Schnorr, web-based smart contract wallets such as OISY can self-host BRC20, Ethereum, and native ICP assets.

A further advantage is that canister smart contracts can sign transactions for execution on chains such as Cardano and Solana.

Schnorr in progress

Ethereum asset twins: ckETH and ckERC20

Developers use ICP to custody Ethereum. This new solution brings a new developer experience challenge: Ethereum costs and wait times. To address this, the ICP community uses ckEth ("chain key Ethereum"), a trustless "Twins of Ethereum" hosted on ICP such as “ether twin” called ckETH and “twins'' of ERC20 tokens, such as ckUSDC, ckUSDT, ckUNISWAP, ck1INCH, ckAAVE. These can be directly processed by smart contracts hosted on ICP.

The “chain key” versions of Ethereum assets live on ledgers created by ICP smart contracts, where they can be transferred with 1 second finality and at near zero cost. Moreover, they can be directly processed by canisters that provide web-based wallets, and other web3 services hosted on the ICP, such as SocialFi and GameFi.

To create chain key Ethereum asset twins, a user transfers them to an address provided by their wallet. Then they can be sent to any other chain key address, almost instantly and at miniscule cost, or directly to a standard Ethereum address (causing the twin to return to its native form), after the standard finalization delay and transaction fee.

ckETH doneckERC20 is in progress

icpERC20 tokens on Ethereum

Ethereum provides the world’s preeminent DeFi rails. Decentralized exchanges such as Uniswap provide immense liquidity for trading ERC20 tokens. Popular custody services such as Fireblocks, which is popular among investment institutions, custody any ERC20 token as standard.

The ICP protocol makes it possible to publish any native ICP token hosted on a standard ledger to Ethereum, in the form of an icpERC20. The twin is a standard ERC20 token and can be processed by any service that processes ERC20 tokens.

A service created by a Internet Computer-hosted smart contract provides functionality (often relayed by wallets) to create an icpERC20 twin of an ICP token. The service also allows icpERC20 twins to be returned to the Internet Computer, where they retain their native form.

Once an icpERC20 token has been created, it can be processed by Ethereum Layer-2 networks and moved across other chains using traditional bridges.

icpERC20 is in progress

Ordinals, BRC20 inscriptions from ICP using tSchnorr

Canister smart contracts on the Internet Computer can use a Bitcoin API to process bitcoin, and also Ordinals, which are used to create and transfer NFTs on the Bitcoin blockchain. Fully decentralized Web3 services on the Internet Computer have taken advantage of the functionality to create marketplaces for Ordinals e.g. Bioniq.

Because ICP supports Schnorr, web-based smart contract wallets such as OISY can self-host BRC20, Ethereum, and native ICP assets.

A further advantage is that canister smart contracts can sign transactions for execution on chains such as Cardano and Solana.

Schnorr in progress
